Our precisely dimensioned, one-piece dry cargo floors, with surfaces featuring natural plywood, phenolic resin, GRP anti-slip or aluminium, will boost your productivity. The floors with particularly abrasion-resistant aluminium or GRP surfaces are easy to clean and are also available with recessed airline rails for securing loads. On request, we can weld the aluminium barley grain or low-noise surface (longitudinal grooves) to the surrounding base skirting to form a liquid-tight floor pan. Honeycomb floors could be an option to save weight.
| length in mm (Nominal width 2.550 mm) | Thickness | floor with 2 mm GRP Anti Slipn | floor with alu fine riffle surface | floor with alu low noise surface | floor plywood | floor with phenolic resin | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| in mm | weight (kg) | weight (kg) | weight (kg) | weight (kg) | weight (kg) | |||||||
| 5.800 | 30 | 306 | 375 | 454 | 288 | 296 | ||||||
| 6.200 | 30 | 327 | 402 | 486 | 308 | 317 | ||||||
| 6.600 | 30 | 349 | 428 | 518 | 328 | 336 | ||||||
| 7.000 | 30 | 370 | 455 | 550 | 348 | 355 | ||||||
| 7.400 | 30 | 392 | 481 | 582 | 368 | 374 | ||||||
| 7.800 | 30 | 413 | 508 | 614 | 388 | 394 | ||||||
| 8.200 | 30 | 432 | 534 | 646 | 408 | 414 |
