Drawbar Spring Saddle E5, left/right
Weight: 5 kg
- steel raw
- spring width 80 mm
- bush-Ø 24/28 mm
- height 100 mm
Drawbar Spring Saddle
Weight: 4 kg
- steel raw
- spring width 100 mm
- bush-Ø 30 mm
- height 120 mm
Drawbar Spring Saddle
Weight: 3 kg
- steel raw
- spring width 100 mm
- bush-Ø 30 mm
- height 100 mm
Flat Spring Saddle E3
Weight: 2 kg
- steel raw
- spring width 70 mm
- bush Ø 22/26 mm
with slot - height 90 mm
Flat Spring Saddle
Weight: 1.2 kg
- steel raw
- spring width 60 mm
- bush Ø 20/24 mm
with slot - height 67 mm
Flat Spring Saddle
Weight: 1.4 kg
- steel raw
- spring width 60 mm
- bush Ø 20/24 mm
with slot - height 87 mm
Flat Spring Saddle E5
Weight: 3 kg
- steel raw
- spring width 80 mm
- bush Ø 24/28 mm
with slot - height 100 mm
Flat Spring Saddle E11
Weight: 4 kg
- steel raw
- spring width 100 mm
- bush Ø 26/30 mm
with slot - height 100 mm
Flat Spring Saddle
Weight: 3.5 kg
- steel raw
- spring width 100 mm
- bush Ø 30/30 mm
- height 100 mm
Flat Spring Saddle
Weight: 3.5 kg
- steel raw
- spring width 100 mm
- bush Ø 40/40 mm
with slot - height 100 mm
Sliding Spring Saddle E3
Weight: 4 kg
- steel raw
- height 150 mm
- spring width 70 mm
- bush Ø 17 mm
Sliding Spring Saddle E5
Weight: 7 kg
- steel raw
- height 190 mm
- spring width 80 mm
bush Ø 17 mm
Sliding Spring Saddle E11
Weight: 9 kg
- steel raw
- height 220 mm
- spring width 100 mm
- bush Ø 17 mm
Sliding Spring Saddle
Weight: 3.5 kg
- steel raw
- height 170 mm
- spring width 60 mm
bush Ø 15 mm
Front Spring Saddle for tandem units
Weight: 3 kg
- steel raw
- spring width 70 mm
- bush Ø 22/26
with slot
Front Spring Saddle for tandem units
Weight: 3 kg
- steel raw
- spring width 80 mm
- bush Ø 24/28 mm
with slot
Front Spring Saddle for tandem units
Front Spring Saddle for tandem units
Sliding Spring Saddle for tandem units
Weight: 4 kg
- steel raw
- spring width 70 mm
- bush Ø 17 mm
- height 195 mm
Sliding Spring Saddle for tandem units
Weight: 5 kg
- steel raw
- spring width 80 mm
- bush Ø 17 mm
- height 218 mm
Sliding Spring Saddle for tandem units
Weight: 7 kg
- steel raw
- spring width 80 mm
- bush Ø 17 mm
- height 285 mm
Sliding Spring Saddle for tandem units
Weight: 5 kg
- steel raw
- spring width 80 mm
- bush Ø 17 mm
- height 230 mm
Spring Saddle Back High without flange
Weight: 4 kg
- steel raw
- spring width 70 mm
- bush Ø 30/30 mm
with slot
Spring Saddle Back High with flange left/right
Weight: 5 kg
- steel raw
- spring width 80 mm
- bush Ø 30/30 mm
with slot
Spring Saddle Back High for tandem units
Spring Saddle Back High with flange
